Havit 12V LED signage modules with three bright white LEDs per unit, connected by flexible wiring for professional use.

LED Signage Module Light 12v DC in 3000k/5500k/RGB Havit Lighting - HV9794-IP65

Name: LED Signage Module Light 12v DC in 3000k/5500k/RGB Havit Lighting - HV9794-IP65
Brand: Havit Lighting
SKU: HV9794-IP65-10-3K
Price: 32.83 NZD
Availability: InStock
Rating: 5.0 (1 reviews)

$32.83 $39.05

LED signage modules, 12v, IP65, packs of 10 or 20

These chained LED modules are made for lighting signs, lightboxes and channel letters from the inside. Each compact module holds 3 LEDs behind a 120° beam, spreading light evenly across the face of a sign.

Choose 3000k warm white, 5500k daylight or RGB colour, in packs of 10 or 20 modules. They are IP65 rated, dimmable, and run on 12v DC.

Key features

3 LEDs per module, 0.72w per module
Up to 60 lumens per module
120° beam angle
Each module 83.8mm long, 15.5mm wide, 5.8mm high
CRI 80
12v DC, up to 20 modules per run, dimmable
IP65 rated
3 year replacement warranty

Colour temperature and output

Colour	Output per module	Best for
3000k Warm White	57 lumens	Hospitality signage, warm toned lightboxes
5500k Daylight	60 lumens	Shop signs, lightboxes, channel letters
RGB	Not published	Colour signage and feature displays (needs an RGB controller)

Choosing a driver and controller

Allow 0.72w for every module and add about 20% headroom. A full run of 20 modules draws 14.4w, so it needs a 12v driver of at least 18w, which in practice means a 30w driver. For bigger signs, split the modules into runs of 20 or fewer and feed each run separately. The RGB version also needs an RGB controller rated for the full load. In damp or exposed locations, use a weatherproof IP66 or IP67 driver or keep the driver under cover. To dim the white modules, pair them with a dimmable 12v driver and a compatible dimmer.

IP65 rated, suitable for damp or sheltered locations such as covered signage.

3 years warranty for extra peace of mind

Dimmable fixture, letting you choose the brightness that's right for your room

Water & dust rated IP65; fully dust-tight and protected against low-pressure water jets from any direction.
